ItemKP-5K31/30C40-101
NameElectro Proportional Pressure Reducing Valve
Plug(24V)Flow(L/min)10L/min
Pressure(Pro) -
ItemKD-5K31/G24DA40
NameElectro Magnetic On-off Valve
Plug(24V)Flow(L/min)16L/min
Pressure(Pro) -
ItemKP-5K31/30C50-107
NameElectro Proportional Pressure Reducing Valve
Plug(24V)Flow(L/min)10L/min
Pressure(Pro) -
ItemTD-51AB
NameElectro Magnetic On-off Valve
Plug(24V)Flow(L/min)10L/min
Pressure(Pro)50bar
-
ItemTD-61AB
NameElectro Magnetic On-off Valve
Plug(24V)Flow(L/min)15L/min（pressure difference between fuel inlet and fuel outlet is 6bar）
Pressure(Pro)50bar
-
ItemHP-E98G38
NameElectro Proportional Pressure Control Valve
Plug(24V)Flow(L/min)23L/mim(Differential pressure：6bar）
Pressure(Pro)0~20bar、0~25bar、0~30bar
-
ItemTD-61AK
NameElectro Magnetic On-off Valve
Plug(24V)Flow(L/min)15L/min（pressure difference between fuel inlet and fuel outlet is 6bar）
Pressure(Pro)50bar
-
ItemHD-0833
NameElectro Magnetic On-off Valve
Plug(24V)Flow(L/min)11L/min（when @7bar）
Pressure(Pro)207bar（All oil ports can be fully pressurized）
-
ItemHD-0830
NameElectro Magnetic On-off Valve
Plug(24V)Flow(L/min)13L/min（when @7bar）
Pressure(Pro)207bar
-
ItemHD-98G38
NameElectro Magnetic On-off Valve
Plug(24V)Flow(L/min)30L/min
Pressure(Pro)45bar
