Control Method：2-way, 2-port, proportional control；

Power off：fuel flows from port ① to port ②；

Power on：Stop the flow of fuel from port ① to port ②；

Application：Proportional pressure reduction control devices

Working Voltage：DC12V/DC24V《Optional》；

Recommended dither frequency：140Hz；

Maximum Flow：1L/min（Flow capacity）；

Maximum Fuel Supply Pressure：P=350bar；

Hysteresis：Under vibration＜4%，DC drive＜8%；

Linearity：≤2%，Repeatability＜2%；

Reset: >85% of setting value；

To achieve the best performance, an amplifier with current sensing and adjustable dither is

required. The dither should be adjustable between 100~250Hz.；

Proportional relief pressure characteristics：see ” Functional Chart”（The test data is when the

rated flow rate is 0.37L/min）；

Maximum leakage during reset： ＜25ml/min；

Usage Environment Temperature：-30℃ to 90℃；

Usage Medium Temperature：-30℃ to 120℃；

Usage Medium Viscosity Range： 5~500cSt mineral oil or lubricating synthetic oil；

Installation：Screw cartridge, tightening torque 35~40Nm；

Coil ：12V/24V "optional", consult the factory for detailed parameters；

IP Functions：IP69

订货代码

Consult the factory for other plugs
